RUIJIE 16-PORT 10/100MBPS DESKTOP POE UNMANAGED+2SFP SWITCH RG-ES118FGS-LP
Click to open expanded view
Brand keytechonline.com
Title RUIJIE 16-PORT 10/100MBPS DESKTOP POE UNMANAGED+2SFP SWITCH RG-ES118FGS-LP

RUIJIE 16-PORT 10/100MBPS DESKTOP POE UNMANAGED+2SFP SWITCH RG-ES118FGS-LP

SPECIFICATION

BRAND : RUIJIE

MANUFACTURE : SWITCH

MODEL : RG-ES118FGS-LP

PoE PORTS : 16 10/100

MAX POE BUDGET : 130W

MANAGED TYPE : UNMANAGED

LAYER TYPE : L-2

SFP PORT : 2

DESCRIPTION

RG-ES118FGS-LP16-Port 10/100 Mbps with 2-Port 10/100/1000 Mbps, 2 Combo Ports Unmanaged PoE Switch, RG-ES118FGS-LP- Total number of RJ45 ports 18, Total number of optical ports 2, Number of 1GE combo ports 2, Number of 1GE SFP ports 2, Number of 10/100BASE-T ports 16, Number of 10/100/1000BASE-T ports 2, Ultra-long-haul transmission Yes, DIP switch- Extend mode: The rate of Ports 1 to 8 is reduced to 10 Mbps, but the maximum transmission distance can be up to 200 meters (Cate5e cables required). Flow control on. Default mode: All ports can communicate with each other. Flow control on. Isolation mode: Ports 1 to 16 cannot communicate with each other, but they can communicate with ports 17 and 18. Flow control on,

Power Supply and Consumption- PoE Out standard PoE/PoE+ (IEEE 802.3af/at), Number of PoE Out ports 16, Number of PoE/PoE+ Out ports 16, PoE budget 120 W, PoE power pins 1–2 (+), 3–6 (-), Power input 220 V AC power supply:  Rated input voltage: 100 V AC to 240 V AC, 50 Hz to 60 Hz Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz Rated input current: 3 A, Maximum power consumption 10 W (with no PoE load)130 W (with PoE full load), Power supply Fixed power supply,

System Specifications- Flash memory 4 MB, Forwarding rate 5.3 Mpps, Switching capacity 7.2 Gbps(bit/s), Dimensions and Weight Casing Metal, Product dimensions (W x D x H) 440 mm x 214.9 mm x 44 mm (17.32 in. x 8.46 in. x 1.73 in.), Weight 2.46 kg (5.42 lbs) (without packaging materials)3 kg (6.61 lbs) (with packaging materials), Environment and Reliability Fan Fanless design, Cooling Natural cooling, Mounting options Rack, ESD protection Air discharge: 8 kVContact discharge: 6 Kv.

Price
40.000 KD
Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

  • We offer free shipping on all orders over 100 KD within the Kuwait city and Salmiya Shuwaikh.
  • For orders under 100 KD, a flat shipping fee of 3 KD for Accessories will be applied and 5 KD for Network Cabinets.
